blasphemour All American 57594 Posts user info edit post |
this is from http://www.specialized.com
FRAME A1 Premium Aluminum, double butted TT, ORE DT, externally relieved head tube, reinforced disc mount, forged dropouts w/ replaceable 98954020 hanger REAR SHOCK N/A FORK RockShox Dart 3 SL, 100mm, Mag Lower, 28.6mm Cro-Mo stanchions, coil spring, alloy steer, rebound adjust w/ lockout and preload adjust HEADSET 1 1/8" threadless STEM Specialized 3D forged alloy, two bolt, 25.4mm, 10 degree rise HANDLEBARS Alloy 25.4mm XC Rise, 640mm wide, 8 degree back, 6 degree up sweep, 3.2mm thick TAPE / GRIPS Specialized Enduro, dual density Kraton FRONT BRAKE Tektro "V" w/ linear spring REAR BRAKE Tektro "V" w/ linear spring BRAKE LEVERS Shimano EF-50 integrated FRONT DERAILLEUR Shimano Acera M-330 REAR DERAILLEUR Shimano Alivio M-410 SHIFT LEVERS Shimano EF-50 CASSETTE / FREEWHEEL Shimano HG-40, 8-speed, 11-32t CHAIN Shimano HG-50, 1/2" x 3/32" CRANKSET Shimano FCM-341-8, Octalink Spline, replaceable rings CHAINRINGS 42S/32S/22S BOTTOM BRACKET Shimano ES-25, Octalink Spline, cartridge bearing, 68 x 126mm for 50mm chain line PEDALS Steel cage, plastic body, 9/16" RIMS Specialized/Alex RH 26, double wall, CNC side walls FRONT HUB Specialized, forged alloy, 32h, QR REAR HUB Shimano FH-RM30L, cassette, 32h, QR SPOKES 1.8mm (15g) stainless FRONT TIRE Specialized Fast Trak, 26x2.0", 60TPI, wire bead REAR TIRE Specialized Fast Trak, 26x2.0", 60TPI, wire bead TUBES Specialized schraeder valve SADDLE Specialized Body Geometry, ATB SEAT POST Alloy micro adjust, 30.9mm SEAT BINDER Specialized forged alloy w/ QR NOTES Chain stay protector, reflectors, clear coat, owners manual
Size 13 15 17 19 21 23 Seat Tube Length, Center to Top 330.2mm 381mm 431.8mm 482.6mm 533.4mm 609.6mm Seat Tube Length, Center to Center 247.5mm 298.5mm 349.5mm 400.5mm 451.5mm 502.5mm Top Tube Length (Horizontal) 545mm 565mm 590mm 615mm 640mm 660mm Top Tube Length (Actual) 546mm 551mm 568mm 590mm 615mm 640mm Bottom Bracket Drop 36mm 36mm 36mm 36mm 36mm 36mm Bottom Bracket Height 299.3mm 299.3mm 299.3mm 299.3mm 299.3mm 299.3mm Chainstay Length 426mm 426mm 426mm 426mm 426mm 426mm Seat Tube Angle 73° 73° 73° 73° 73° 73° Head Tube Angle 70° 70° 70° 70° 70° 70° Rake 38mm 38mm 38mm 38mm 38mm 38mm Trail 82mm 82mm 82mm 82mm 82mm 82mm Front Center 606mm 610.5mm 632.1mm 652.6mm 678.7mm 704.7mm Wheel Base 1030mm 1033.9mm 1055.5mm 1076.1mm 1102.2mm 1128.3mm Standover Height 687.8mm 709.3mm 744.3mm 777.3mm 814.3mm 849.3mm Head Tube Length 100mm 100mm 110mm 120mm 140mm 160mm TT is measured horizontally from center of HT to center of ST 2/8/2007 1:07:48 PM |
